Description:
* Model Number:GHAG Series Plastic Distribution Box
* Material: Insulation, Fire-Proof type refractory material
* Color: White
* Rated Current: 1 Way to 4 Way: 50A; 6 Way to 18 Way: 63A.
* Composition Structure:Removable matte blocks to increase the poles. The removable various size holes are available on the box of
up and down, bottom in case of connecting wires in and out.
* Samples: Distribution Box's samples is available.
Feature
* GHAG series of surface box is kind of good-looking outline small volume. Easy to install economically modular distribution
box. It mainly use for building electric distribution system's installation, matched and house rebuild fitment etc application.
* Qualification Certificate: CE , RoHS and etc.
* Delivery Time: Within 25 days after receipt deposit.
* Delivery Methods: By Sea or By Air ( Express DHL, FEDEX, TNT, UPS or EMS)
* Payment Terms: T/T, Western Union, Paypal
* Unit Price: Distribution Box's price is negotiable.
| Parameter | Value | Parameter | Value |
|---|
| Rated Voltage | 12V | Temperature range | -40℃~+80℃ |
| Rated Current | 20A | Protection Level | IP65 |
| Place of Origin | Zhejiang, China | Product feature | Waterproof, dustproof, corrosion resistant, high strength insulation |
| Brand Name | OUYI | Function | Electric Energy Distribute |
| Model Number | GHAG | Material | ABS Body,PC window |
| OEM Support | Yes | MOQ | 100pcs |
| MODEL | L(mm) | W(mm) | H(mm) | PCS/CTN |
|---|
| GHAG-1WAY | 34 | 130 | 60 | 300 |
| GHAG-2WAYS | 52 | 130 | 60 | 240 |
| GHAG-4WAYS | 87 | 130 | 60 | 150 |
| GHAG-6WAYS | 125 | 160 | 60 | 120 |
| GHAG-8WAYS | 160 | 160 | 60 | 60 |
| GHAG-12WAYS | 258 | 160 | 60 | 20 |
| GHAG-18WAYS | 365 | 160 | 60 | 20 |
